Product Details
- Size: 10
- Place of Origin: Guangdong
- Brand Name: HIPS
- Model Number: QY-1601
- Weight: 25.000 kg
| HIPS-QY1601 | ||||
| High Impact Polystyrene | ||||
| Main features | Application | |||
| Good Mechanical performance | Injection moulding | |||
| Good dimensional stability | Home applications | |||
| Excellent thermal stability and performance | ||||
| Color black | Food grade raw material | |||
| Properties | ||||
| TEST | Method | Condition | Results | |
| Notch impact strength | ISO180 | 25℃ | ≥7.5 | kj/㎡ |
| Tensile strength | ISO527 | 50mm/min | ≥22 | Mpa |
| Elongation | ISO527 | 50mm/min | ≥20 | % |
| Bending Strength | ISO178 | 2mm/min | ≥30 | Mpa |
| Bending modulus | ISO178 | 2mm/min | ≥1800 | Mpa |
| Others | ||||
| Density | ASTMD792 | 25℃ | 1.03-1.06 | g/cm3 |
| M.I. | ASTMD1238 | 200℃/5KG | 5 | g/10min |
| Elements | ||||
| Test | Instruments | Condition | Results | |
| Cd | EDS-1800B | 25℃ | ﹤75 | mg/kg |
| Pb | 25℃ | ﹤90 | mg/kg | |
| Hg | 25℃ | ﹤60 | mg/kg | |
| Cr | 25℃ | ﹤100 | mg/kg | |
| Br | 25℃ | ﹤300 | mg/kg | |
| Processing condition | ||||
| Typical | Range | |||
| Melt temperature | 220℃ | 200-240℃ | ||
| Barrel Temperature | Back | 200℃ | 180-210℃ | |
| Middle | 210℃ | 200-230℃ | ||
| Anterior | 210℃ | 190-230℃ | ||
| Mold temperature | 50℃ | 30-60℃ | ||
| Processing temperature | 240℃ | |||
| Injection Speed | Low to medium | |||
| Back pressure | 10MPa | |||
| Pre-drying | 75℃,2hr | |||
| Above data just for reference, according to different requirements will have different adjustments | ||||
